The goal of the game is to uncover all the squares that do not contain mines.
#include <xtd/forms/about_dialog>
#include "minesweeper.h"
#include "custom_field_dialog.h"
#include "input_name_dialog.h"
using namespace minesweeper;
void minesweeper_form::main() {
application::run(minesweeper_form());
}
minesweeper_form::minesweeper_form() {
icon(properties::resources::minesweeper_ico());
game_panel_.double_buffered(true);
game_panel_.location({0, 60});
game_panel_.parent(*this);
game_panel_.mouse_up += {*this, &minesweeper_form::on_game_panel_mouse_up};
game_panel_.paint += {*this, &minesweeper_form::on_game_panel_paint};
status_panel_.height(60);
status_panel_.parent(*this);
status_panel_.paint += {*this, &minesweeper_form::on_status_panel_paint};
status_panel_.resize += {*this, &minesweeper_form::on_status_panel_resize};
mine_count_label_.auto_size(true);
mine_count_label_.back_color(color::black);
mine_count_label_.fore_color(color::red);
mine_count_label_.height(38);
mine_count_label_.location({17, 17});
mine_count_label_.parent(status_panel_);
mine_count_label_.segment_style(forms::segment_style::modern);
mine_count_label_.text("000");
mine_count_label_.thickness(5);
stopwatch_label_.parent(status_panel_);
stopwatch_label_.height(38);
stopwatch_label_.auto_size(true);
stopwatch_label_.back_color(color::black);
stopwatch_label_.fore_color(color::red);
stopwatch_label_.segment_style(forms::segment_style::modern);
stopwatch_label_.text("000");
stopwatch_label_.thickness(5);
start_game_.parent(status_panel_);
start_game_.image(
bitmap {properties::resources::smiley1(), {24, 24}});
start_game_.size({42, 38});
start_game_.location({status_panel_.size().width() / 2 - 21, 17});
start_game_.click += {*this, &minesweeper_form::new_game};
stopwatch_timer_.interval_milliseconds(1000);
stopwatch_timer_.tick += {*this, &minesweeper_form::on_stopwatch_tick};
update_colors();
change_level(as<level>(properties::settings::default_settings().level()));
}
void minesweeper_form::change_level(level
l) {
properties::settings::default_settings().level(as<int>(l));
properties::settings::default_settings().save();
level_ = l;
cells_.clear();
grid_size_ = std::map<minesweeper::level, grid_size> {{minesweeper::level::beginner, {9, 9}}, {minesweeper::level::intermediate, {16, 16}}, {minesweeper::level::expert, {30, 16}}, {minesweeper::level::custom, {properties::settings::default_settings().custom_width(), properties::settings::default_settings().custom_height()}}} [level_];
mine_count_ = std::map<minesweeper::level, int> {{minesweeper::level::beginner, 10}, {minesweeper::level::intermediate, 40}, {minesweeper::level::expert, 99}, {minesweeper::level::custom, properties::settings::default_settings().custom_mines()}} [level_];
game_panel_.size({30 + grid_size_.width() * cell::width(), 30 + grid_size_.height() * cell::height()});
cells_ = row_cell(grid_size_.width(), column_cell(grid_size_.height()));
status_panel_.width(game_panel_.width());
new_game();
}
void minesweeper_form::new_game() {
game_over_ = false;
stopwatch_timer_.enabled(false);
checked_cell_count_ = 0;
flagged_mine_count_ = 0;
stopwatch_count_ = 0;
for (
auto y = 0;
y < grid_size_.height(); ++
y)
for (
auto x = 0;
x < grid_size_.width(); ++
x)
for (auto count = 0; count < mine_count_; ++count) {
auto x = rand.
next(0, grid_size_.width() - 1);
auto y = rand.
next(0, grid_size_.height() - 1);
if (cells_[
x][
y].contains_mine()) {
count--;
continue;
}
cells_[
x][
y].has_mine(
true);
}
for (
auto y = 0;
y < grid_size_.height(); ++
y)
for (
auto x = 0;
x < grid_size_.width(); ++
x)
for (
auto yy =
y - 1; yy <=
y + 1; ++yy)
for (
auto xx =
x - 1; xx <=
x + 1; ++xx)
if (yy >= 0 && yy < grid_size_.height() && xx >= 0 && xx < grid_size_.width() && cells_[xx][yy].contains_mine())
cells_[
x][
y].neighbors(cells_[
x][
y].number_of_neighbouring_mines() + 1);
mine_count_label_.text(ustring::format("{:D3}", mine_count_ - flagged_mine_count_));
stopwatch_label_.text("000");
start_game_.image(
bitmap {properties::resources::smiley1(), {24, 24}});
invalidate();
}
void minesweeper_form::check_neighbors(
const point& cell_location) {
if (checked_cell(cell_location) != 0) return;
for (
auto y = cell_location.
y() - 1;
y <= cell_location.
y() + 1; ++
y)
for (
auto x = cell_location.
x() - 1;
x <= cell_location.
x() + 1; ++
x)
if (
y >= 0 &&
y < grid_size_.height() &&
x >= 0 &&
x < grid_size_.width() && cells_[
x][
y].state() == cell_state::unchecked && checked_cell({
x,
y}) == 0)
}
int minesweeper_form::checked_cell(
const point& cell_location) {
if (cells_[cell_location.
x()][cell_location.
y()].state() == cell_state::unchecked) {
cells_[cell_location.
x()][cell_location.
y()].state(cell_state::checked);
checked_cell_count_++;
}
return cells_[cell_location.
x()][cell_location.
y()].number_of_neighbouring_mines();
}
static std::map<cell_state, delegate<void(paint_event_args&, const rectangle&, minesweeper::cell)>> draw_state {{cell_state::unchecked, {*this, &minesweeper_form::draw_unchecked}}, {cell_state::checked, {*this, &minesweeper_form::draw_checked}}, {cell_state::flag, {*this, &minesweeper_form::draw_flag}}, {cell_state::question, {*this, &minesweeper_form::draw_question}}, {cell_state::mine, {*this, &minesweeper_form::draw_mine}}, {cell_state::exploded_mine, {*this, &minesweeper_form::draw_exploded_mine}}, {cell_state::error, {*this, &minesweeper_form::draw_error}}};
draw_state[cell.state()](e, clip_rectangle, cell);
}
draw_border_unchecked(e, clip_rectangle);
}
draw_border_checked(e, clip_rectangle);
if (properties::settings::default_settings().original_color()) {
switch (cell.number_of_neighbouring_mines()) {
case 1: text_color = color::blue; break;
case 2: text_color = color::green; break;
case 3: text_color = color::red; break;
case 4: text_color = color::dark_blue; break;
case 5: text_color = color::dark_red; break;
case 6: text_color = color::teal; break;
case 7: text_color = color::dark_magenta; break;
case 8: text_color = color::black; break;
default: return;
}
} else if (back_color().get_brightness() < 0.5f) {
switch (cell.number_of_neighbouring_mines()) {
case 1: text_color = color::light_sky_blue; break;
case 2: text_color = color::from_argb(0x30, 0xDC, 0x66); break;
case 3: text_color = color::from_argb(0xD0, 0x3E, 0x3D); break;
case 4: text_color = color::dodger_blue; break;
case 5: text_color = color::orange; break;
case 6: text_color = color::light_sea_green; break;
case 7: text_color = color::from_argb(0xC6, 0x5E, 0xE9); break;
case 8: text_color = fore_color(); break;
default: return;
}
} else {
switch (cell.number_of_neighbouring_mines()) {
case 1: text_color = color::blue; break;
case 2: text_color = color::green; break;
case 3: text_color = color::red; break;
case 4: text_color = color::dodger_blue; break;
case 5: text_color = color::dark_orange; break;
case 6: text_color = color::teal; break;
case 7: text_color = color::dark_magenta; break;
case 8: text_color = fore_color(); break;
default: return;
}
}
}
draw_border_unchecked(e, clip_rectangle);
static auto flag =
bitmap {properties::resources::flag(), {16, 16}};
auto x = clip_rectangle.
left() + (clip_rectangle.
width() - flag.width()) / 2;
auto y = clip_rectangle.
top() + (clip_rectangle.
height() - flag.height()) / 2;
}
draw_border_unchecked(e, clip_rectangle);
auto question_color = back_color().get_brightness() < 0.5f ? color::light_sky_blue : color::blue;
}
draw_border_checked(e, clip_rectangle);
static auto mine =
bitmap {properties::resources::mine(), {16, 16}};
auto x = clip_rectangle.
left() + (clip_rectangle.
width() - mine.width()) / 2;
auto y = clip_rectangle.
top() + (clip_rectangle.
height() - mine.height()) / 2;
}
draw_mine(e, clip_rectangle, cell);
}
draw_border_checked(e, clip_rectangle);
draw_mine(e, clip_rectangle, cell);
}
if (!properties::settings::default_settings().original_color()) {
}
e.
graphics().
draw_line(
pen {color::light(color::light(color::light(back_color())))}, clip_rectangle.
left(), clip_rectangle.
top(), clip_rectangle.
right(), clip_rectangle.
top());
}
}
void minesweeper_form::game_over() {
stopwatch_timer_.enabled(false);
game_over_ = true;
start_game_.image(
bitmap {properties::resources::smiley2(), {24, 24}});
for (
auto y = 0;
y < grid_size_.height(); ++
y) {
for (
auto x = 0;
x < grid_size_.width(); ++
x) {
if (cells_[
x][
y].state() == cell_state::exploded_mine)
continue;
if (cells_[
x][
y].state() == cell_state::flag && !cells_[
x][
y].contains_mine())
cells_[
x][
y].state(cell_state::error);
if (cells_[
x][
y].state() != cell_state::flag && cells_[
x][
y].contains_mine())
cells_[
x][
y].state(cell_state::mine);
}
}
}
void minesweeper_form::mark_cell(
int x,
int y) {
auto& cell = cells_[
x][y];
if (cell.state() == cell_state::unchecked) {
cell.state(cell_state::flag);
++flagged_mine_count_;
} else if (cell.state() == cell_state::flag && properties::settings::default_settings().marks()) {
cell.state(cell_state::question);
--flagged_mine_count_;
} else if (cell.state() == cell_state::flag || cell.state() == cell_state::question) cell.state(cell_state::unchecked);
if ((mine_count_ - flagged_mine_count_) >= 0 && (mine_count_ - flagged_mine_count_) <= 999) mine_count_label_.text(ustring::format("{:D3}", mine_count_ - flagged_mine_count_));
else if (mine_count_ - flagged_mine_count_ >= -99) mine_count_label_.text(ustring::format("{:D2}", mine_count_ - flagged_mine_count_));
invalidate();
}
void minesweeper_form::on_about_menu_click(
object& sender,
const xtd::event_args& e) {
dialog.
icon(properties::resources::minesweeper_png());
dialog.name("Minesweeper"_t);
dialog.version("1.0");
dialog.long_version("1.0.0");
dialog.description("The goal of the game is to uncover all the squares\nthat do not contain mines."_t);
dialog.copyright("Copyright (c) 2023 Gammasoft.\nAll rights reserved."_t);
dialog.website("https://gammasoft71.wixsite.com/gammasoft"_t);
dialog.website_label("gammasoft website"_t);
dialog.license("MIT License\n"
"\n"
"Copyright (c) 2023 Gammasoft.\n"
"\n"
"Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the \"Software\"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions:\n"
"\n"
"The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software.\n"
"\n"
"THE SOFTWARE IS PROVIDED \"AS IS\", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.\n");
dialog.show();
}
void minesweeper_form::on_help_content_menu_click(
object& sender,
const xtd::event_args& e) {
diagnostics::process::start("https://github.com/gammasoft71/xtd/blob/master/examples/xtd.forms.examples/games/minesweeper/resources/help.md");
}
void minesweeper_form::on_custom_menu_click(
object& sender,
const xtd::event_args& e) {
auto dialog = custom_field_dialog {};
dialog.custom_height(properties::settings::default_settings().custom_height());
dialog.custom_width(properties::settings::default_settings().custom_width());
dialog.custom_mines(properties::settings::default_settings().custom_mines());
dialog.show_dialog(*this);
properties::settings::default_settings().custom_height(dialog.custom_heght());
properties::settings::default_settings().custom_width(dialog.custom_width());
properties::settings::default_settings().custom_mines(dialog.custom_mines());
properties::settings::default_settings().save();
change_level(level::custom);
}
void minesweeper_form::on_game_panel_mouse_up(
object& sender,
const mouse_event_args& e) {
if (game_over_) return;
stopwatch_timer_.enabled(true);
if (e.
location().
x() < 15 || e.
location().
y() < 15 || e.
location().
x() >= (grid_size_.width() * cell::width() + 15) || e.
location().
y() >= (grid_size_.height() * cell::height() + 15))
return;
auto y = (e.
location().
y() - 15) / cell::height();
if (e.
button() == mouse_buttons::right) mark_cell(
x,
y);
else if (e.
button() == mouse_buttons::left) uncover_cell(
x,
y);
}
void minesweeper_form::on_game_panel_paint(
object& sender,
paint_event_args& e) {
auto offset = 12;
for (
auto y = 0;
y < grid_size_.height(); ++
y)
for (
auto x = 0;
x < grid_size_.width(); ++
x)
draw_cell(e, {15 +
x * cell::width(), 15 +
y * cell::height(), cell::width(), cell::height()}, cells_[
x][
y]);
}
void minesweeper_form::on_marks_menu_click(
object& sender,
const xtd::event_args& e) {
properties::settings::default_settings().marks(!properties::settings::default_settings().marks());
properties::settings::default_settings().save();
}
void minesweeper_form::on_original_color_menu_click(
object& sender,
const xtd::event_args& e) {
properties::settings::default_settings().original_color(!properties::settings::default_settings().original_color());
properties::settings::default_settings().save();
update_colors();
}
void minesweeper_form::on_status_panel_paint(
object& sender,
paint_event_args& e) {
auto offset = 12;
}
void minesweeper_form::on_status_panel_resize(
object& sender,
const event_args& e) {
start_game_.location({status_panel_.size().width() / 2 - 21, 17});
stopwatch_label_.location({status_panel_.width() - stopwatch_label_.width() - 18, 17});
}
void minesweeper_form::on_stopwatch_tick() {
if (stopwatch_count_ < 999)
stopwatch_label_.text(ustring::format("{:D3}", ++stopwatch_count_));
}
void minesweeper_form::uncover_cell(
int x,
int y) {
start_game_.image(
bitmap(properties::resources::smiley4(), {24, 24}));
application::do_events();
if (cells_[
x][y].state() == cell_state::question)
cells_[
x][y].state(cell_state::unchecked);
if (cells_[
x][y].state() == cell_state::unchecked) {
if (cells_[
x][y].contains_mine()) {
cells_[
x][y].state(cell_state::exploded_mine);
game_over();
} else {
if (grid_size_.width() * grid_size_.height() - checked_cell_count_ != mine_count_) start_game_.image(
bitmap(properties::resources::smiley1(), {24, 24}));
else you_win();
}
invalidate();
}
}
void minesweeper_form::update_colors() {
back_color(properties::settings::default_settings().original_color() ? color::from_argb(192, 196, 200) : default_back_color());
fore_color(properties::settings::default_settings().original_color() ? color::black : default_fore_color());
}
void minesweeper_form::you_win() {
stopwatch_timer_.enabled(false);
game_over_ = true;
for (
auto y = 0;
y < grid_size_.height(); ++
y)
for (
auto x = 0;
x < grid_size_.width(); ++
x)
if (cells_[
x][
y].state() != cell_state::flag && cells_[
x][
y].contains_mine())
cells_[
x][
y].state(cell_state::mine);
start_game_.image(
bitmap(properties::resources::smiley3(), {24, 24}));
mine_count_label_.text("000");
if (level_ != level::custom && stopwatch_count_ < std::map<level, int> {{level::beginner, properties::settings::default_settings().beginner_high_scores_value()}, {level::intermediate, properties::settings::default_settings().intermediate_high_scores_value()}, {level::expert, properties::settings::default_settings().expert_high_scores_value()}} [level_]) {
auto gamer_name = std::map<level, ustring> {{level::beginner, properties::settings::default_settings().beginner_high_scores_name()}, {level::intermediate, properties::settings::default_settings().intermediate_high_scores_name()}, {level::expert, properties::settings::default_settings().expert_high_scores_name()}} [level_];
minesweeper::input_name_dialog input_name_dialog;
input_name_dialog.gammer_name(gamer_name);
input_name_dialog.level(level_);
if (input_name_dialog.show_dialog(*this) == dialog_result::ok)
gamer_name = input_name_dialog.gammer_name();
std::map<level, delegate<void(int)>> set_settings_high_scores_values {{level::beginner, {properties::settings::default_settings(), &properties::settings::beginner_high_scores_value}}, {level::intermediate, {properties::settings::default_settings(), &properties::settings::intermediate_high_scores_value}}, {level::expert, {properties::settings::default_settings(), &properties::settings::expert_high_scores_value}}};
std::map<level, delegate<void(ustring)>> set_settings_high_scores_names {{level::beginner, {properties::settings::default_settings(), &properties::settings::beginner_high_scores_name}}, {level::intermediate, {properties::settings::default_settings(), &properties::settings::intermediate_high_scores_name}}, {level::expert, {properties::settings::default_settings(), &properties::settings::expert_high_scores_name}}};
set_settings_high_scores_values[level_](stopwatch_count_);
set_settings_high_scores_names[level_](gamer_name);
properties::settings::default_settings().save();
minesweeper::high_scores_dialog().show_dialog(*this);
}
}
