base class for full (dense) matrix eigenvalue SOE solvers. More...
#include <FullGenEigenSolver.h>
Public Member Functions | |
| virtual int | solve (void) |
| Causes the solver to compute the solution of the system of equations. More... | |
| virtual int | solve (int numEigen) |
| virtual int | setSize (void) |
| const int & | getSize (void) const |
| Return the eigenvectors dimension. | |
| virtual bool | setEigenSOE (FullGenEigenSOE &theSOE) |
| Sets the eigenproblem to solve. | |
| virtual const Vector & | getEigenvector (int mode) const |
| virtual const double & | getEigenvalue (int mode) const |
| int | sendSelf (CommParameters &) |
| Send the object. More... | |
| int | recvSelf (const CommParameters &) |
| Receive the object. More... | |
 Public Member Functions inherited from XC::EigenSolver | |
| const int & | getNumModes (void) const |
| Vector | getNormalizedEigenvector (int mode) const |
| Returns the autovector of the i-th mode normalized so the maximal component is 1 (infinity norm). More... | |
| Matrix | getEigenvectors (void) const |
| Returns a matrix of eigenvectors disposed in columns. | |
| Matrix | getNormalizedEigenvectors (void) const |
| Returns a matrix with the normalized eigenvectors disposed in columns (infinity norm). More... | |
| double | getAngularFrequency (int mode) const |
| Return the angular frequency for the i-th mode. | |
| double | getPeriodo (int mode) const |
| Returns the period for the i-th mode. | |
| double | getFrecuencia (int mode) const |
| Return the frecuency for the i-th mode. | |
| Vector | getEigenvalues (void) const |
| Returns a vector con los eigenvalues calculados. | |
| Vector | getAngularFrequencies (void) const |
| Returns a vector with the computed angular frequencies for each mode. More... | |
| Vector | getPeriodos (void) const |
| Returns a vector with the computed periods for each mode. More... | |
| Vector | getFrecuencias (void) const |
| Returns a vector with the computed frequencies for each mode. More... | |
| Public Member Functions inherited from XC::MovableObject | |
| MovableObject (int classTag, int dbTag) | |
| Constructor. More... | |
| MovableObject (int classTag) | |
| Constructor. More... | |
| MovableObject (const MovableObject &) | |
| Copy constructor. Doesn't copy the dbTag. | |
| MovableObject & | operator= (const MovableObject &) |
| Assignment operator. Doesn't copy the dbTag. | |
| int | getClassTag (void) const |
| Return the class identifier. | |
| int | getDbTag (void) const |
| Return the object identifier in the database. | |
| int | getDbTag (CommParameters &) |
| Return the object identifier in the database. | |
| void | setDbTag (int dbTag) |
| Sets the object identifier in the database. | |
| void | setDbTag (CommParameters &) |
| Sets the object identifier in the database if not already set. More... | |
| virtual int | setParameter (const std::vector< std::string > &argv, Parameter ¶m) |
Sets the value param to the parameter argv. | |
| virtual int | updateParameter (int parameterID, Information &info) |
Updates the parameter identified by parameterID with info. | |
| virtual int | activateParameter (int parameterID) |
Activates the parameter identified by parameterID. | |
| virtual int | setVariable (const std::string &variable, Information &) |
Set the value of the variable idenfified by var. | |
| virtual int | getVariable (const std::string &variable, Information &) |
Return the value of the variable idenfified by var. | |
| Public Member Functions inherited from XC::DistributedBase | |
| DistributedBase (void) | |
| Constructor. | |
| virtual DbTagData & | getDbTagData (void) const |
| Returns a vector to store class dbTags. | |
| const int & | getDbTagDataPos (const int &i) const |
| Returns the data at the i-th position. | |
| void | setDbTagDataPos (const int &i, const int &v) |
| Sets the data at the i-th position. | |
| void | inicComm (const int &dataSize) const |
| Initializes communication. | |
Friends | |
| class | EigenSOE |
Additional Inherited Members | |
| Protected Member Functions inherited from XC::EigenSolver | |
| EigenSolver (const int &classTag, const int &nModes=0) | |
| Constructor. | |
| Protected Member Functions inherited from XC::Solver | |
| Solver (int classTag) | |
| Constructor. More... | |
| Protected Attributes inherited from XC::EigenSolver | |
| int | numModes |
| number of eigenvalues to compute. | |
Detailed Description
base class for full (dense) matrix eigenvalue SOE solvers.
Member Function Documentation
§ recvSelf()
|
virtual |
Receive the object.
Each object has to receive the data needed to be able to recreate itself in the new process after it has been sent through cp. If the object is an aggregation containing other objects, new objects of the correct type can be constructed using #theBroker. To return 0 if successful or a -1 if not.
Implements XC::MovableObject.
§ sendSelf()
|
virtual |
Send the object.
Each object has to send the data needed to be able to reproduce that object in a remote process. The object uses the methods provided by cp object to send the data to another channel at the remote actor, the address of the channel is set before this method is called. An object of similar type at the remote actor is invoked with a receiveSelf() to receive the data. Returns 0 if successful (successful in that the data got to the channel), or a - if no data was sent.
Implements XC::MovableObject.
§ solve()
|
virtual |
Causes the solver to compute the solution of the system of equations.
Return $0$ if successful , negative number if not; the actual value depending on the type of Solver.
Implements XC::EigenSolver.
The documentation for this class was generated from the following files:
- src/solution/system_of_eqn/eigenSOE/FullGenEigenSolver.h
- src/solution/system_of_eqn/eigenSOE/FullGenEigenSolver.cpp
