Base class for buttons. More...

Inheritance diagram for HoloToolkit.Unity.Buttons.Button:

Public Member Functions
void	OnInputDown (InputEventData eventData)
	Handle on input down events from IInputHandler. More...

void	OnInputUp (InputEventData eventData)
	Handle on input up events from IInputHandler. More...

void	OnInputClicked (InputClickedEventData eventData)
	Handle clicked events from IInputClickHandler. More...

void	OnHoldStarted (HoldEventData eventData)
	Handle OnHoldStarted events from IHoldHandler. More...

void	OnHoldCompleted (HoldEventData eventData)
	Handle on hold completed events from IHoldHandler. More...

void	OnHoldCanceled (HoldEventData eventData)
	Handle on hold canceled events from IHoldHandler. More...

void	OnFocusEnter (PointerSpecificEventData eventData)
	Handle on focus enter events from IPointerSpecificFocusable. More...

void	OnFocusExit (PointerSpecificEventData eventData)
	Handle on focus exit events from IPointerSpecificFocusable. More...

virtual void	OnHandVisibleChange (bool visible)
	Event to fire off when hand/spatial input source visibility changes. More...

virtual void	OnStateChange (ButtonStateEnum newState)
	Callback virtual function for when the button state changes. More...

void	TriggerClicked ()
	Public function to force a clicked event on a button. More...

Protected Member Functions
virtual void	OnDisable ()
	Ensures the button returns to a neutral state when disabled More...

void	DoButtonPressed ()
	Called when the button is pressed down. More...

void	DoButtonReleased ()
	Called when the button is released. More...

void	DoButtonClicked ()

void	DoButtonHeld ()
	Called once after the button is held down. More...

void	DoButtonCanceled ()
	Called when something interrupts the button pressed state. More...

Protected Attributes
string	_GizmoIcon
	Protected string for the current active gizmo icon More...

Properties
ButtonStateEnum	ButtonState `[get, set]`
	Current Button State. More...

InteractionSourcePressInfo	ButtonPressFilter `[get, set]`
	Filter to apply for the correct button source. More...

bool	RequireGaze `[get, set]`
	If true, the interactable will deselect when you look off of the object. More...

Events
Action< ButtonStateEnum >	StateChange
	Event to receive button state change. More...

Action< GameObject >	OnButtonPressed
	Event fired when tap interaction received. More...

Action< GameObject >	OnButtonReleased
	Event fired when released interaction received. More...

Action< GameObject >	OnButtonClicked
	Event fired when click interaction received. More...

Action< GameObject >	OnButtonHeld
	Event fired when hold interaction initiated. More...

Action< GameObject >	OnButtonCanceled
	Event fired when button interaction canceled. More...

Detailed Description

Base class for buttons.

Definition at line 14 of file Button.cs.

Member Function Documentation

§ DoButtonCanceled()

void HoloToolkit.Unity.Buttons.Button.DoButtonCanceled ( )

protected

Called when something interrupts the button pressed state.

Definition at line 341 of file Button.cs.

§ DoButtonClicked()

void HoloToolkit.Unity.Buttons.Button.DoButtonClicked ( )

protected

Definition at line 319 of file Button.cs.

§ DoButtonHeld()

void HoloToolkit.Unity.Buttons.Button.DoButtonHeld ( )

protected

Called once after the button is held down.

Definition at line 330 of file Button.cs.

§ DoButtonPressed()

void HoloToolkit.Unity.Buttons.Button.DoButtonPressed ( )

protected

Called when the button is pressed down.

Definition at line 290 of file Button.cs.

§ DoButtonReleased()

void HoloToolkit.Unity.Buttons.Button.DoButtonReleased ( )

protected

Called when the button is released.

Definition at line 309 of file Button.cs.

§ OnDisable()

virtual void HoloToolkit.Unity.Buttons.Button.OnDisable ( )

protectedvirtual

Ensures the button returns to a neutral state when disabled

Definition at line 135 of file Button.cs.

§ OnFocusEnter()

void HoloToolkit.Unity.Buttons.Button.OnFocusEnter ( PointerSpecificEventData eventData )

Handle on focus enter events from IPointerSpecificFocusable.

Implements HoloToolkit.Unity.InputModule.IPointerSpecificFocusable.

Definition at line 239 of file Button.cs.

§ OnFocusExit()

void HoloToolkit.Unity.Buttons.Button.OnFocusExit ( PointerSpecificEventData eventData )

Handle on focus exit events from IPointerSpecificFocusable.

Implements HoloToolkit.Unity.InputModule.IPointerSpecificFocusable.

Definition at line 257 of file Button.cs.

§ OnHandVisibleChange()

virtual void HoloToolkit.Unity.Buttons.Button.OnHandVisibleChange ( bool visible )

virtual

Event to fire off when hand/spatial input source visibility changes.

Parameters

visible Whether the spatial input source is has become visible.

Definition at line 355 of file Button.cs.

§ OnHoldCanceled()

void HoloToolkit.Unity.Buttons.Button.OnHoldCanceled ( HoldEventData eventData )

Handle on hold canceled events from IHoldHandler.

Parameters

eventData

Implements HoloToolkit.Unity.InputModule.IHoldHandler.

Definition at line 226 of file Button.cs.

§ OnHoldCompleted()

void HoloToolkit.Unity.Buttons.Button.OnHoldCompleted ( HoldEventData eventData )

Handle on hold completed events from IHoldHandler.

Parameters

eventData

Implements HoloToolkit.Unity.InputModule.IHoldHandler.

Definition at line 217 of file Button.cs.

§ OnHoldStarted()

void HoloToolkit.Unity.Buttons.Button.OnHoldStarted ( HoldEventData eventData )

Handle OnHoldStarted events from IHoldHandler.

Parameters

eventData

Implements HoloToolkit.Unity.InputModule.IHoldHandler.

Definition at line 203 of file Button.cs.

§ OnInputClicked()

void HoloToolkit.Unity.Buttons.Button.OnInputClicked ( InputClickedEventData eventData )

Handle clicked events from IInputClickHandler.

Parameters

eventData

Implements HoloToolkit.Unity.InputModule.IInputClickHandler.

Definition at line 185 of file Button.cs.

§ OnInputDown()

void HoloToolkit.Unity.Buttons.Button.OnInputDown ( InputEventData eventData )

Handle on input down events from IInputHandler.

Parameters

eventData

Implements HoloToolkit.Unity.InputModule.IInputHandler.

Definition at line 151 of file Button.cs.

§ OnInputUp()

void HoloToolkit.Unity.Buttons.Button.OnInputUp ( InputEventData eventData )

Handle on input up events from IInputHandler.

Parameters

eventData

Implements HoloToolkit.Unity.InputModule.IInputHandler.

Definition at line 168 of file Button.cs.

§ OnStateChange()

virtual void HoloToolkit.Unity.Buttons.Button.OnStateChange ( ButtonStateEnum newState )

virtual

Callback virtual function for when the button state changes.

Parameters

newState A ButtonStateEnum for the new button state.

Reimplemented in HoloToolkit.Unity.Buttons.ObjectButton, HoloToolkit.Unity.Buttons.MeshButton, HoloToolkit.Unity.Buttons.SpriteButton, HoloToolkit.Unity.Buttons.AnimControllerButton, and HoloToolkit.Unity.Buttons.AnimButton.

Definition at line 399 of file Button.cs.

§ TriggerClicked()

void HoloToolkit.Unity.Buttons.Button.TriggerClicked ( )

Public function to force a clicked event on a button.

Definition at line 417 of file Button.cs.

Member Data Documentation

§ _GizmoIcon

string HoloToolkit.Unity.Buttons.Button._GizmoIcon

protected

Protected string for the current active gizmo icon

Definition at line 95 of file Button.cs.

Property Documentation

§ ButtonPressFilter

InteractionSourcePressInfo HoloToolkit.Unity.Buttons.Button.ButtonPressFilter

getset

Filter to apply for the correct button source.

Definition at line 40 of file Button.cs.

§ ButtonState

ButtonStateEnum HoloToolkit.Unity.Buttons.Button.ButtonState

getset

Current Button State.

Definition at line 27 of file Button.cs.

§ RequireGaze

bool HoloToolkit.Unity.Buttons.Button.RequireGaze

getset

If true, the interactable will deselect when you look off of the object.

Definition at line 53 of file Button.cs.

Event Documentation

§ OnButtonCanceled

Action<GameObject> HoloToolkit.Unity.Buttons.Button.OnButtonCanceled

Event fired when button interaction canceled.

Definition at line 86 of file Button.cs.

§ OnButtonClicked

Action<GameObject> HoloToolkit.Unity.Buttons.Button.OnButtonClicked

Event fired when click interaction received.

Definition at line 76 of file Button.cs.

§ OnButtonHeld

Action<GameObject> HoloToolkit.Unity.Buttons.Button.OnButtonHeld

Event fired when hold interaction initiated.

Definition at line 81 of file Button.cs.

§ OnButtonPressed

Action<GameObject> HoloToolkit.Unity.Buttons.Button.OnButtonPressed

Event fired when tap interaction received.

Definition at line 66 of file Button.cs.

§ OnButtonReleased

Action<GameObject> HoloToolkit.Unity.Buttons.Button.OnButtonReleased

Event fired when released interaction received.

Definition at line 71 of file Button.cs.

§ StateChange

Action<ButtonStateEnum> HoloToolkit.Unity.Buttons.Button.StateChange

Event to receive button state change.

Definition at line 61 of file Button.cs.

The documentation for this class was generated from the following file:

Assets/HoloToolkit/UX/Scripts/Buttons/Button.cs
