Some 3d object may contain some head on display objects. More...

#include <IHeadOn3D.h>

Inheritance diagram for ParaEngine::IHeadOn3D:

Public Member Functions
void	SetHeadOnText (const char *sText, int nIndex=0)
	set the text to be displayed on head on display

const char *	GetHeadOnText (int nIndex=0)
	Get the text to be displayed on head on display.

void	SetHeadOnUITemplateName (const char *sUIName, int nIndex=0)
	set which UI control the head on display will be used as a template for drawing the text it can be a single CGUIText Object or it can be a container with a direct children called "text" if this is "" or empty, the default UI template will be used. More...

const char *	GetHeadOnUITemplateName (int nIndex=0)
	get which UI control the head on display will be used as a template for drawing the text it can be a single CGUIText Object or it can be a container with a direct children called "text" if this is "" or empty, the default UI template will be used. More...

const std::string &	GetHeadOnUITemplateNameS (int nIndex=0)

virtual CGUIBase *	GetHeadOnUIObject (int nIndex=0)

void	SetHeadOnTextColor (DWORD color, int nIndex=0)
	set the text to be displayed on head on display

DWORD	GetHeadOnTextColor (int nIndex=0)
	Get the text to be displayed on head on display.

void	SetHeadOnOffest (const Vector3 &vOffset, int nIndex=0)
	set the offset where head on display should be rendered relative to the origin or head of the host 3d object

void	GetHeadOnOffset (Vector3 *pOut, int nIndex=0)
	Get the offset where head on display should be rendered relative to the origin or head of the host 3d object.

void	ShowHeadOnDisplay (bool bShow, int nIndex=0)
	show or hide object's head on display

bool	IsHeadOnDisplayShown (int nIndex=0)
	whether the object head on display shall be visible

bool	IsHeadOnZEnabled (int nIndex=0)
	whether z buffer test is enabled for Head On display. More...

void	SetHeadOnZEnabled (bool bZnabled, int nIndex=0)
	set if z buffer test is enabled for Head On display. More...

virtual bool	HasHeadOnDisplay (int nIndex=0)
	whether the object contains head on display at given index

bool	IsHeadOn3DScalingEnabled (int nIndex=0)
	Enable 3d scaling. More...

void	SetHeadOn3DScalingEnabled (bool bZnabled, int nIndex=0)
	Enable 3d scaling.

bool	IsHeadOnUseGlobal3DScaling (int nIndex=0)
	this is only used when m_bEnable3DScaling. More...

void	SetHeadOnUseGlobal3DScaling (bool bZnabled, int nIndex=0)
	this is only used when m_bEnable3DScaling. More...

void	SetHeadOnNearZoomDist (float fValue, int nIndex=0)

float	GetHeadOnNearZoomDist (int nIndex=0)

void	SetHeadOnFarZoomDist (float fValue, int nIndex=0)

float	GetHeadOnFarZoomDist (int nIndex=0)

void	SetHeadOnMinUIScaling (float fValue, int nIndex=0)

float	GetHeadOnMinUIScaling (int nIndex=0)

void	SetHeadOnMaxUIScaling (float fValue, int nIndex=0)

float	GetHeadOnMaxUIScaling (int nIndex=0)

void	SetHeadOnAlphaFadePercentage (float fValue, int nIndex=0)

float	GetHeadOnAlphaFadePercentage (int nIndex=0)

void	SetHeadOn3DFacing (float fValue, int nIndex=0)
	turn on 3d facing when this function is called

float	GetHeadOn3DFacing (int nIndex=0)

Static Public Member Functions
static bool	DrawHeadOnUI (CBaseObject pObj, int &nCounter, SceneState pSceneState=NULL, CGUIText **ppObjUITextDefault=NULL, bool bZEnablePass=true, bool b3DTextPass=false)
	draw the headon UI of a specified object. More...

static bool	BeginPaint (SceneState *pSceneState, bool b3DTextPass, bool bZEnablePass)
	HeadOn UI needs to be drawn between BeginPaint and EndPaint, which is usually automatically when the first and last head on UI is called. More...

static void	EndPaint (SceneState *pSceneState, bool b3DTextPass)

Detailed Description

Some 3d object may contain some head on display objects.

May it be text, icons, or 3D mark, this class provides common interface for such objects. The default implementation is very light-weighted. It only has a pointer and size member storage for object that does not have head on display. each object can have specify multiple head on UI at different index. by default it is index 0.

Member Function Documentation

§ BeginPaint()

bool ParaEngine::IHeadOn3D::BeginPaint	(	SceneState *	pSceneState,
		bool	b3DTextPass,
		bool	bZEnablePass
	)

static

HeadOn UI needs to be drawn between BeginPaint and EndPaint, which is usually automatically when the first and last head on UI is called.

Hence, one usually do not need to call this method.

§ DrawHeadOnUI()

bool ParaEngine::IHeadOn3D::DrawHeadOnUI	(	CBaseObject *	pObj,
		int &	nCounter,
		SceneState *	pSceneState = `NULL`,
		CGUIText **	ppObjUITextDefault = `NULL`,
		bool	bZEnablePass = `true`,
		bool	b3DTextPass = `false`
	)

static

draw the headon UI of a specified object.

call this function in a loop like below { CGUIText* pObjUITextDefault = NULL; int nCounter = 0; for each obj in a render frame { if(IHeadOn3D::DrawHeadOnUI(&obj, nCounter, &sceneState, &pObjUITextDefault) == false) break; } IHeadOn3D::DrawHeadOnUI(NULL, nCounter); }

Parameters

pObj	: if this is NULL, it means the last object. it will stop batch rendering by calling EndPaint()
nCounter	both in and out parameter. if this is 0, it means the start of the character and BeginPaint() is called automatically. this function will automatically increase this value if object is drawn
pSceneState	pointer to a scene state. it can be NULL.
pObjUITextDefault	see the example above for how to use this. It is the default UI template to use if the object does not provide one.
bZEnablePass	if true, we will only draw UI objects with z buffer test enabled. The pipeline will first draw z enabled pass and then non-Z-enabled pass.
b3DTextPass	whether to pass 3d text

Returns: : true if object is drawn.

§ GetHeadOnUITemplateName()

const char * ParaEngine::IHeadOn3D::GetHeadOnUITemplateName ( int nIndex = 0 )

get which UI control the head on display will be used as a template for drawing the text it can be a single CGUIText Object or it can be a container with a direct children called "text" if this is "" or empty, the default UI template will be used.

The default UI template is an invisible CGUIText control called "_HeadOnDisplayText_" By default, "_HeadOnDisplayText_" uses horizontal text alignment and system font.

Returns: : it returns NULL if no UI head on display.

§ IsHeadOn3DScalingEnabled()

bool ParaEngine::IHeadOn3D::IsHeadOn3DScalingEnabled ( int nIndex = 0 )

Enable 3d scaling.

the text are scaled according to camera to object distance fScaling = g_fMaxUIScaling - (fDist - g_fNearZoomDist) / (g_fFarZoomDist - g_fNearZoomDist) * (g_fMaxUIScaling-g_fMinUIScaling);

§ IsHeadOnUseGlobal3DScaling()

bool ParaEngine::IHeadOn3D::IsHeadOnUseGlobal3DScaling ( int nIndex = 0 )

this is only used when m_bEnable3DScaling.

if true, we will use parent SceneObject's paramter for 3d scaling, otherwise the local settings are employed

§ IsHeadOnZEnabled()

bool ParaEngine::IHeadOn3D::IsHeadOnZEnabled ( int nIndex = 0 )

whether z buffer test is enabled for Head On display.

default to true.

§ SetHeadOnUITemplateName()

void ParaEngine::IHeadOn3D::SetHeadOnUITemplateName	(	const char *	sUIName,
		int	nIndex = `0`
	)

set which UI control the head on display will be used as a template for drawing the text it can be a single CGUIText Object or it can be a container with a direct children called "text" if this is "" or empty, the default UI template will be used.

The default UI template is an invisible CGUIText control called "_HeadOnDisplayText_" By default, "_HeadOnDisplayText_" uses horizontal text alignment and system font.

Parameters

nIndex there can be several UI template at position 0,1,2,.. so that position 0 may be used for character name, index 1 for group name, index 2 for question mark icon,etc.

§ SetHeadOnUseGlobal3DScaling()

void ParaEngine::IHeadOn3D::SetHeadOnUseGlobal3DScaling	(	bool	bZnabled,
		int	nIndex = `0`
	)
