Crombie Tools
|
Can be created using the CrombieTools.AnalysisTools.XSecAdder module. More...
#include <XSecAdder.h>
Public Member Functions | |
XSecAdder (TString name="XSecWeight") | |
Constructor setting the name of a branch it would like to write to. More... | |
virtual | ~XSecAdder () |
void | AddMergeBranch (TString name) |
Add a branch to merge into the new cross section branch. More... | |
void | AddXSecs () |
Loops through all the stored files and adds a XSec branch to the right tree. More... | |
void | SetBranchName (TString name) |
Set the name of the branch to write to. More... | |
void | SetInTreeName (TString name) |
Set the name of the tree to read to get number of events. More... | |
void | SetOutTreeName (TString name) |
Set the name of the tree to write to. More... | |
Public Member Functions inherited from ParallelRunner | |
void | SetNumThreads (UInt_t nthreads) |
Set the number of cores to use in the plotting. More... | |
Public Member Functions inherited from FileConfigReader | |
FileConfigReader () | |
virtual | ~FileConfigReader () |
void | AddDataFile (TString fileName) |
Add a data file. More... | |
void | AddFile (TString treeName, TString fileName, Double_t XSec, TString entry="", Int_t colorstyle=0) |
This is the default MC File adder. More... | |
void | AddFile (TString treeName, TString fileName, Double_t XSec, TString entry, Int_t colorstyle, FileType type) |
Default File adder with FileType changing. More... | |
void | AddFile (TString fileName, Double_t XSec, TString entry, Int_t colorstyle) |
This is for when you don't care about limit trees and are adding by hand. More... | |
void | AddFile (TString fileName, Double_t XSec, TString entry, Int_t colorstyle, FileType type) |
For when you don't care about limit trees and are adding by hand with type changing. More... | |
FileType | GetFileType () |
Get the FileType of the current file. More... | |
void | LoadFitResult (const char *fit_result) |
Loads the fit result into memory for this stacks to make. More... | |
void | NameTreesAfterLimits (FileType type=kBackground) |
Use this function to replace the Legend Entries of the FileInfo with the Limit Tree Names. More... | |
void | ReadMCConfig (TString config, TString fileDir="") |
Reads an MC configuration file. More... | |
void | ReadMCConfig (TString config, FileType type, TString fileDir="") |
Reads an MC configuration while changing the FileType. More... | |
void | ResetAllConfig () |
Resets the information from the config files being held for all types. More... | |
void | ResetConfig (FileType type=kBackground) |
Resets the information from the for one type. More... | |
std::vector< TString > | ReturnFileNames (FileType type=kBackground, TString matchName="", SearchBy search=kLimitName, Bool_t match=true) |
Returns a vector of file names that have been read from the configs. More... | |
TChain * | ReturnTChain (TString treeName="events", FileType type=kBackground, TString matchName="", SearchBy search=kLimitName, Bool_t match=true) |
Returns a TChain of files that match the FileType and name for the LimitTreeMaker. More... | |
std::set< TString > | ReturnTreeNames (FileType type=kBackground) |
Returns a vector of limit tree names that have been read from the configs. More... | |
void | ScaleBackgrounds (TString entry, Double_t scale, SearchBy search=kLimitName, FileType type=kBackground) |
Scales the cross section of the matching MC samples by a factor of 1.0 + scale, destroying the old cross section in the process. More... | |
void | SetAllHistName (TString name) |
Set the all histogram and luminosity for normalization. More... | |
void | SetDataEntry (TString entry) |
Set the legend entry for data. More... | |
void | SetDataExpression (TString expr) |
Use this to set a different expression for data from MC. More... | |
void | SetDataTreeName (TString name) |
Set the tree name for data. More... | |
void | SetDataWeight (TCut weight) |
The multipliers for Data can be set separately. More... | |
void | SetDataWeight (const char *weight) |
The multipliers for Data can be set separately. More... | |
void | SetFileType (FileType type) |
Set the FileType of the next config file read. More... | |
void | SetKeepAllFiles (Bool_t keep) |
Allows reader to avoid skipping when reading in exception configs. More... | |
void | SetLegendColor (TString entry, Int_t color, FileType type=kBackground) |
Sets the FileInfo with the matching Legend Names to the new colors. More... | |
void | SetLuminosity (Double_t lum) |
Set the Luminosity in inverse pb. More... | |
void | SetMCWeight (TCut weight) |
The multipliers for MC can be set separately. More... | |
void | SetMCWeight (const char *weight) |
The multipliers for MC can be set separately. More... | |
void | SetTreeName (TString name) |
Set the tree of the files you are trying to plot. More... | |
Public Member Functions inherited from InOutDirectoryHolder | |
InOutDirectoryHolder () | |
virtual | ~InOutDirectoryHolder () |
TString | GetOutDirectory () const |
void | SetInputOutputMap (TString input, TString output) |
Adds a mapping from input to output file name. More... | |
void | SetOutDirectory (TString dir) |
Sets the output directory where the files will be written, and adds a "/" if needed. More... | |
void | SetOverwriteFiles (Bool_t overwrite) |
Sets whether or not to overwrite files. More... | |
Public Member Functions inherited from InDirectoryHolder | |
InDirectoryHolder () | |
virtual | ~InDirectoryHolder () |
TString | GetInDirectory () const |
void | SetInDirectory (TString dir) |
Sets the input directory where the MCFiles will be searched for, and adds a "/" if needed. More... | |
Public Member Functions inherited from Debug | |
Debug () | |
virtual | ~Debug () |
DebugLevel | GetDebugLevel () |
Gets the verbosity for a class. More... | |
template<typename T , typename... V> | |
void | Message (DebugLevel level, T message, V... more) |
Sends a message if the verbosity level is appropriate. More... | |
void | Message (DebugLevel level) |
void | SetDebugLevel (DebugLevel level) |
Sets the verbosity for a class. More... | |
Public Member Functions inherited from PlotHists | |
PlotHists () | |
virtual | ~PlotHists () |
void | AddUncertainty (UInt_t index, TString FileName, TString HistName, Int_t startBin=1, Int_t endBin=0) |
Add uncertainty factors to some index of histograms about to be made. More... | |
virtual void | MakeCanvas (TString FileBase, Int_t NumXBins, Double_t *XBins, TString XLabel, TString YLabel, Bool_t logY=false) |
Alternatively, we can set values in PlotBase and then just give the binning. More... | |
virtual void | MakeCanvas (TString FileBase, Int_t NumXBins, Double_t MinX, Double_t MaxX, TString XLabel, TString YLabel, Bool_t logY=false) |
void | MakeCanvas (TString FileBase, std::vector< TH1D *> theHists, TString XLabel, TString YLabel, Bool_t logY=false) |
Simplest of Canvas makers with just histograms as arugments, allowing for user manipulation of histograms. More... | |
std::vector< TH1D * > | MakeHists (Int_t NumXBins, Double_t *XBins) |
This just return vectors of histograms for other uses. More... | |
std::vector< TH1D * > | MakeHists (Int_t NumXBins, Double_t MinX, Double_t MaxX) |
void | SetEventsPer (Double_t per) |
We can set events per some value of x so that our legend entry is not wrong and variable binning doesn't look stupid. More... | |
void | SetNormalizedHists (Bool_t b) |
We can set normalization to match a particular other hist (or just 1) More... | |
void | SetNormalizeTo (Int_t to) |
Set index of which histogram to normalize to. More... | |
void | SetUncertaintySquared (TString expr) |
Add uncertainty factors through branch expressions instead of a histogram. More... | |
Public Member Functions inherited from PlotBase | |
PlotBase () | |
virtual | ~PlotBase () |
void | AddCutLine (Double_t loc, bool is_vert=true) |
Adds a dotted line in order to show cuts. More... | |
void | AddExpr (TString expr) |
Set an x expression for a single line. More... | |
void | AddLegendEntry (TString LegendEntry, Color_t ColorEntry) |
Set entry and color for each line. This uses the default line width and style. More... | |
void | AddLegendEntry (TString LegendEntry, Color_t ColorEntry, Int_t LineWidth, Int_t LineStyle) |
Set entry, color, width, and style for each line. More... | |
void | AddLine (TTree *tree, TCut cut, TString expr) |
This function adds a tree pointer, cut, and expression used for generating a line in the plot. More... | |
void | AddLine (TTree *tree, const char *cut, TString expr) |
This function adds a tree pointer, cut, and expression used for generating a line in the plot. More... | |
void | AddRatioLine (Int_t line) |
Add a line to show in the ratio plot. More... | |
void | AddSystematicBranch (TString branch) |
Add branches that contain independent systematic uncertainties to show in the plots. More... | |
void | AddTree (TTree *tree) |
Set a tree for a single line. More... | |
void | AddTreeExpr (TTree *tree, TString expr) |
Set a tree and expression concurrently for each line. Best used when a default weight is set. More... | |
void | AddTreeWeight (TTree *tree, TCut cut) |
Set a tree and weight concurrently for each line. Best used when a default expression is set. More... | |
void | AddTreeWeight (TTree *tree, const char *cut) |
Set a tree and weight concurrently for each line. Best used when a default expression is set. More... | |
void | AddWeight (TCut cut) |
Set a weight for a single line. More... | |
void | AddWeight (const char *cut) |
Set a weight for a single line. More... | |
void | AddWeightExpr (TCut cut, TString expr) |
Set a weight and expression concurrently for each line. Best used when a default tree is set. More... | |
void | AddWeightExpr (const char *cut, TString expr) |
Set a weight and expression concurrently for each line. Best used when a default tree is set. More... | |
TCut | GetDefaultWeight () const |
Get the default weight. More... | |
void | OnlyPDF () |
Call this before plotting to only write plots to .pdf files. More... | |
void | OnlyPNG () |
Call this before plotting to only write plots to .png files. More... | |
void | ResetCutLines () |
Resets the number of cut lines to plot. More... | |
void | ResetExpr () |
Reset the list of expressions used to makes lines. More... | |
void | ResetLegend () |
Resets the legend entries for each line. More... | |
void | ResetSystematics () |
Reset list of branches that contain systematics. More... | |
void | ResetTree () |
Reset the list of trees used to makes lines. More... | |
void | ResetWeight () |
Reset the list of weights used to makes lines. More... | |
void | SetAxisMinMax (Float_t min, Float_t max) |
Forces the minimum and maximum values of the Y-axis in the plot. More... | |
void | SetAxisTitleOffset (Float_t offset) |
Sets the offset of the Y-axis title as a ratio of the default offset. More... | |
void | SetCanvasName (TString name) |
Sets the name of the canvas created by PlotBase. More... | |
void | SetCanvasSize (Int_t width, Int_t height) |
Sets the size of the output canvas. More... | |
void | SetCMSLabel (TString type) |
Set the type of CMS label for the plot. More... | |
void | SetCutLineStyle (Color_t color, Int_t width, Int_t style) |
Sets the style for the cut lines. More... | |
void | SetDataIndex (Int_t data) |
Set one of the lines to be plotted as data. More... | |
void | SetDefaultCut (const char *cut) |
void | SetDefaultExpr (TString expr) |
Set the default expression to be plotted on the x-axis for each line in the plot. More... | |
void | SetDefaultLineStyle (Int_t style) |
Set the default line style. More... | |
void | SetDefaultLineWidth (Int_t width) |
Set the default line width. More... | |
void | SetDefaultTree (TTree *tree) |
Set the default tree pointer for each line in the plot. More... | |
void | SetDefaultWeight (TCut cut) |
Set the default weight for each line in the plot. More... | |
void | SetDefaultWeight (const char *cut) |
Set the default weight for each line in the plot. More... | |
void | SetDrawFirst (Int_t first) |
Force a line to draw first on the plot, if desired. More... | |
void | SetDrawOpts (TString options) |
Set additional drawing options to force all lines to have. More... | |
void | SetFontSize (Float_t fontSize) |
Sets the fontsize of the axis labels. More... | |
void | SetIncludeErrorBars (Bool_t include) |
Set this to true to feature error bars in the plots. More... | |
void | SetLeftMargin (float left) |
void | SetLegendBorderSize (Int_t size) |
Set the legend border size. More... | |
void | SetLegendFill (Bool_t fill) |
If true, the legend will be filled with a solid background. More... | |
void | SetLegendLimits (Double_t lim1, Double_t lim2, Double_t lim3, Double_t lim4) |
Set the legend location manually. More... | |
void | SetLegendLocation (LegendY yLoc, LegendX xLoc, Double_t xWidth=0.3, Double_t yWidth=0.2) |
Set the legend location using LegendY and LegendX enums. More... | |
void | SetLumiLabel (TString lumi) |
Set the luminosity label. More... | |
void | SetLumiLabel (Float_t lumi) |
Set the luminosity lable with a float in fb. More... | |
void | SetLumiLabelFormat (TString format) |
Set the luminosity format. More... | |
void | SetMakeRatio (Bool_t ratio) |
If true, a ratio pad will be drawn underneath. More... | |
void | SetRatioDivisions (Int_t divisions, Bool_t optimize=true) |
Sets the divisions of the ratio y axis. More... | |
void | SetRatioGrid (Int_t grid) |
Set horizontal dotted lines on the ratio pad. More... | |
void | SetRatioIndex (Int_t ratio) |
Set which line will be '1' in the ratio plot. More... | |
void | SetRatioMinMax (Float_t min, Float_t max) |
Force the minimum and maximum values of the ratio pad. More... | |
void | SetRatioTitle (TString title) |
Set the y axis label of the ratio pad. More... | |
void | SetTreeList (std::vector< TTree *> treelist) |
Can store multiple trees at once for plots. Each tree plots its own line. More... | |
Private Member Functions | |
void | RunFile (FileInfo &info) |
Run over a single file. More... | |
Private Attributes | |
TString | fBranchName |
Name of Branch to write to. More... | |
TString | fInTreeName = "events" |
Name of Tree to read to get number of events. More... | |
std::vector< TString > | fMergeBranches |
List of branches to merge into the new branch. More... | |
TString | fOutTreeName = "events" |
Name of Tree to write to. More... | |
Additional Inherited Members | |
Public Types inherited from FileConfigReader | |
enum | FileType { kBackground = 0, kSignal, kData } |
Differentiates between background, signal MC and data. More... | |
enum | SearchBy { kLimitName = 0, kLegendEntry } |
Determines how to match to return files. More... | |
Public Types inherited from Debug | |
enum | DebugLevel { eQuiet = 0, eError, eInfo, eDebug } |
Different possible debug levels. More... | |
Public Types inherited from PlotBase | |
enum | LegendX { kLeft = 0, kRight } |
Used for horizontal position of legend. More... | |
enum | LegendY { kUpper = 0, kLower } |
Used for vertical position of legend. More... | |
Protected Member Functions inherited from ParallelRunner | |
void | RunThreads () |
Run over all of the filled FileInfos. More... | |
Protected Member Functions inherited from FileConfigReader | |
void | CloseFiles () |
Closes the files that are open. More... | |
std::vector< FileInfo * > * | GetFileInfo (FileType type) |
Return a pointer to a proper vector of FileInfo. More... | |
TH1D * | GetHist (std::vector< TH1D *> HistList) |
Draw a single histogram using the default expression and a file list. More... | |
TH1D * | GetHist (Int_t NumXBins, Double_t *XBins, std::vector< TString > FileList, FileType type) |
Draw a single histogram using the default expression and a file list. More... | |
TH1D * | GetHist (Int_t NumXBins, Double_t *XBins, FileType type, TString matchName="", SearchBy search=kLimitName, Bool_t match=true) |
Draw a single histogram using the default expression and file configuration. More... | |
std::vector< TH1D * > | GetHistList (Int_t NumXBins, Double_t *XBins, std::vector< TString > FileList, FileType type) |
Draws histograms for using the default expression and a file list. More... | |
std::vector< TH1D * > | GetHistList (Int_t NumXBins, Double_t *XBins, FileType type, TString matchName="", SearchBy search=kLimitName, Bool_t match=true) |
Draws histograms for using the default expression and file configuration. More... | |
void | OpenFiles (std::vector< TString > fileNames) |
Opens the files in a vector. More... | |
void | SetMultiplyLumi (Bool_t doMultiply) |
Allows reader to avoid skipping when reading in exception configs. More... | |
Protected Member Functions inherited from InOutDirectoryHolder | |
TString | AddOutDir (TString FileName) const |
A helper function that prepends the output directory to a filename. More... | |
Protected Member Functions inherited from InDirectoryHolder | |
TString | AddInDir (TString FileName) |
A helper function that prepends the input directory to a filename. More... | |
Protected Member Functions inherited from Debug | |
void | DisplayFunc (const char *func) |
Sends the name of the function during debuggin. More... | |
Protected Member Functions inherited from PlotBase | |
template<class T > | |
void | BaseCanvas (TString FileBase, std::vector< T *> theLines, TString XLabel, TString YLabel, Bool_t logY=false, Bool_t logX=false) |
This is the powerhouse of all the plotting tools. Everything happens here. More... | |
void | ConvertToArray (Int_t NumXBins, Double_t MinX, Double_t MaxX, Double_t *XBins) |
Takes number of bins, min and max, and dumps it into an already allocated array. More... | |
TString | TempHistName () |
Get a temporary name for a histogram. More... | |
Protected Attributes inherited from FileConfigReader | |
TString | fAllHistName = "htotal" |
The all histogram name used ingenerating cross section weights. More... | |
TString | fDataEntry = "Data" |
The legend entry for data. More... | |
std::vector< FileInfo * > | fDataFileInfo |
Vector of data FileInfo objects. More... | |
TString | fDataTreeName = "data" |
The base name of the data in a limit tree. More... | |
TCut | fDataWeight = "" |
Separate Data weights if needed. More... | |
Double_t | fLuminosity = 2000.0 |
The Luminosity in inverse pb. More... | |
std::vector< FileInfo * > | fMCFileInfo |
Vector of background FileInfo objects. More... | |
TCut | fMCWeight = "" |
Separate MC weights if needed. More... | |
std::vector< FileInfo * > | fSignalFileInfo |
Vector of signal FileInfo objects. More... | |
TString | fTreeName = "events" |
Stores name of tree from file. More... | |
Protected Attributes inherited from PlotHists | |
Double_t | fEventsPer = 0 |
Histogram normalized to events per units of X axis. More... | |
Protected Attributes inherited from PlotBase | |
Bool_t | bC = true |
If true, BaseCanvas will create a .C macro. More... | |
Bool_t | bPDF = true |
If true, BaseCanvas will create a .pdf file. More... | |
Bool_t | bPNG = true |
If true, BaseCanvas will create a .png file. More... | |
Float_t | fAxisMax = 0.0 |
Maximum value of the y-axis. More... | |
Float_t | fAxisMin = 0.0 |
Minimum value of the y-axis. More... | |
Int_t | fDataIndex = -1 |
Index in the plotter of the data line. More... | |
TCut | fDefaultCut = "" |
Default cut if needed. More... | |
TString | fDefaultExpr = "" |
Default resolution expression if needed. More... | |
TTree * | fDefaultTree = NULL |
Default Tree if needed. More... | |
Bool_t | fIncludeErrorBars = true |
Option to include error bars. More... | |
std::vector< TCut > | fInCuts |
Holds the cuts for the trees if needed. More... | |
std::vector< TString > | fInExpr |
Holds multiple resolution expressions if needed. More... | |
std::vector< TTree * > | fInTrees |
Holds all the trees for each line if needed. More... | |
Int_t | fLegendBorderSize = 0 |
Border size of legend. More... | |
std::vector< TString > | fLegendEntries |
Number of legend entries should match number of lines. More... | |
Bool_t | fMakeRatio = false |
Bool to make a ratio plot on bottom of image. More... | |
Bool_t | fOptimDivisions |
UInt_t | fPlotCounter = 0 |
This is used so that making scratch plots does not overlap. More... | |
Int_t | fRatioDivisions |
Int_t | fRatioGrid |
Int_t | fRatioIndex = -1 |
Pick which line to set as 1 in ratio plot. More... | |
std::vector< Int_t > | fRatioLines |
Vector of line indices to show up in the ratio pad. More... | |
Float_t | fRatioMax = 0.0 |
Maximum of the ratio pad. More... | |
Float_t | fRatioMin = 0.0 |
Minimum of the ratio pad. More... | |
TString | fRatioTitle |
Label of the ratio pad. More... | |
std::vector< TString > | fSystematicBranches |
Vector of branches to apply as systematic uncertainties. More... | |
Double_t | l1 = 0.6 |
First X value of legend location. More... | |
Double_t | l2 = 0.7 |
First Y value of legend location. More... | |
Double_t | l3 = 0.9 |
Second X value of legend location. More... | |
Double_t | l4 = 0.9 |
Second Y value of legend location. More... | |
Can be created using the CrombieTools.AnalysisTools.XSecAdder module.
A XSecAdder reads from a config file and adds a branch for a XSec weight. Still needs to be multiplied by Luminosity to get proper number of events.
Definition at line 26 of file XSecAdder.h.
XSecAdder::XSecAdder | ( | TString | name = "XSecWeight" | ) |
Constructor setting the name of a branch it would like to write to.
|
virtual |
Definition at line 25 of file XSecAdder.cc.
|
inline |
Add a branch to merge into the new cross section branch.
Definition at line 43 of file XSecAdder.h.
References fMergeBranches.
void XSecAdder::AddXSecs | ( | ) |
Loops through all the stored files and adds a XSec branch to the right tree.
Definition at line 29 of file XSecAdder.cc.
References ParallelRunner::RunThreads().
|
privatevirtual |
Run over a single file.
Implements ParallelRunner.
Definition at line 34 of file XSecAdder.cc.
References fBranchName, FileInfo::fFileName, sushi::file, fInTreeName, fMergeBranches, fOutTreeName, FileInfo::fXSecWeight, and output_lock.
|
inline |
Set the name of the branch to write to.
Definition at line 41 of file XSecAdder.h.
References fBranchName.
|
inline |
Set the name of the tree to read to get number of events.
Definition at line 37 of file XSecAdder.h.
References fInTreeName.
|
inline |
Set the name of the tree to write to.
Definition at line 39 of file XSecAdder.h.
References fOutTreeName.
|
private |
Name of Branch to write to.
Definition at line 48 of file XSecAdder.h.
Referenced by RunFile(), and SetBranchName().
|
private |
Name of Tree to read to get number of events.
Definition at line 46 of file XSecAdder.h.
Referenced by RunFile(), and SetInTreeName().
|
private |
List of branches to merge into the new branch.
Definition at line 50 of file XSecAdder.h.
Referenced by AddMergeBranch(), and RunFile().
|
private |
Name of Tree to write to.
Definition at line 47 of file XSecAdder.h.
Referenced by RunFile(), and SetOutTreeName().
