A DeviceInterface connected in series with one or more DeviceFilters. Useful for serialization. More...

#include <FilteredDevice.h>

Inheritance diagram for SurgSim::Devices::FilteredDevice:

Public Member Functions
	FilteredDevice (const std::string &name)
	Constructor. More...

	SURGSIM_CLASSNAME (SurgSim::Devices::FilteredDevice)

virtual	~FilteredDevice ()
	Destructor.

std::string	getName () const override
	Return a (hopefully unique) device name.

bool	initialize () override
	Fully initialize the device. More...

bool	isInitialized () const override

bool	addInputConsumer (std::shared_ptr< Input::InputConsumerInterface > inputConsumer) override

bool	removeInputConsumer (std::shared_ptr< Input::InputConsumerInterface > inputConsumer) override

void	clearInputConsumers () override
	Removes all InputConsumers.

bool	setOutputProducer (std::shared_ptr< Input::OutputProducerInterface > outputProducer) override

bool	removeOutputProducer (std::shared_ptr< Input::OutputProducerInterface > outputProducer) override

bool	hasOutputProducer () override
	Query if this object has output producer. More...

void	clearOutputProducer () override
	Removes any OutputProducer.

void	setDevice (std::shared_ptr< Input::DeviceInterface > device)
	Sets the raw/base device. More...

void	addFilter (std::shared_ptr< DeviceFilter > filter)
	Adds a DeviceFilter. More...

const std::vector< std::shared_ptr< Input::DeviceInterface > > &	getDevices () const

bool	setDevices (const std::vector< std::shared_ptr< Input::DeviceInterface >> &devices)
	Sets the devices. More...

Public Member Functions inherited from SurgSim::Input::DeviceInterface
virtual	~DeviceInterface ()
	Virtual destructor (empty).

virtual std::string	getClassName () const =0
	The class name for this class. More...

virtual bool	addInputConsumer (std::shared_ptr< InputConsumerInterface > inputConsumer)=0
	Adds an input consumer that will be notified when the application input state is updated. More...

virtual bool	removeInputConsumer (std::shared_ptr< InputConsumerInterface > inputConsumer)=0
	Removes an input consumer previously added via addInputConsumer. More...

virtual bool	setOutputProducer (std::shared_ptr< OutputProducerInterface > outputProducer)=0
	Sets an output producer that will be asked for application output state when the device needs it. More...

virtual bool	removeOutputProducer (std::shared_ptr< OutputProducerInterface > outputProducer)=0
	Removes an output producer previously added via setOutputProducer. More...

Public Member Functions inherited from SurgSim::Framework::Accessible
	Accessible ()
	Default Constructor.

	~Accessible ()
	Destructor.

template<class T >
T	getValue (const std::string &name) const
	Retrieves the value with the name by executing the getter if it is found and tries to convert it to the given type. More...

boost::any	getValue (const std::string &name) const
	Retrieves the value with the name by executing the getter if it is found. More...

template<class T >
bool	getValue (const std::string &name, T *value) const
	Retrieves the value with the name by executing the getter if it is found, and converts it to the type of the output parameter. More...

void	setValue (const std::string &name, const boost::any &value)
	Sets a value of a property that has setter. More...

bool	isReadable (const std::string &name) const
	Check whether a property is readable. More...

bool	isWriteable (const std::string &name) const
	Check whether a property is writable. More...

void	setGetter (const std::string &name, GetterType func)
	Sets a getter for a given property. More...

void	setSetter (const std::string &name, SetterType func)
	Sets a setter for a given property. More...

void	setAccessors (const std::string &name, GetterType getter, SetterType setter)
	Sets the accessors getter and setter in one function. More...

void	removeAccessors (const std::string &name)
	Removes all the accessors (getter and setter) for a given property. More...

void	forwardProperty (const std::string &name, const Accessible &target, const std::string &targetProperty)
	Adds a property with the given name that uses the targets accessors, in effect forwarding the value to the target. More...

void	setSerializable (const std::string &name, EncoderType encoder, DecoderType decoder)
	Sets the functions used to convert data from and to a YAML::Node. More...

void	setDecoder (const std::string &name, DecoderType decoder)
	Sets the functions used to convert data from a YAML::Node. More...

YAML::Node	encode () const
	Encode this Accessible to a YAML::Node. More...

void	decode (const YAML::Node &node, const std::vector< std::string > &ignoredProperties=std::vector< std::string >())
	Decode this Accessible from a YAML::Node, will throw an exception if the data type cannot be converted. More...

std::vector< std::string >	getProperties ()

template<>
boost::any	getValue (const std::string &name) const

Additional Inherited Members
Public Types inherited from SurgSim::Framework::Accessible
typedef std::function< boost::any(void)>	GetterType

typedef std::function< void(boost::any)>	SetterType

typedef std::function< YAML::Node(void)>	EncoderType

typedef std::function< void(const YAML::Node *)>	DecoderType

Public Types inherited from SurgSim::Framework::FactoryBase1< DeviceInterface, std::string >
typedef ObjectFactory1< DeviceInterface, std::string >	FactoryType

Static Public Member Functions inherited from SurgSim::Framework::FactoryBase1< DeviceInterface, std::string >
static FactoryType &	getFactory ()

Detailed Description

A DeviceInterface connected in series with one or more DeviceFilters. Useful for serialization.

Constructor & Destructor Documentation

§ FilteredDevice()

SurgSim::Devices::FilteredDevice::FilteredDevice ( const std::string & name )

explicit

Constructor.

Parameters

name	Name of this device.

Member Function Documentation

§ addFilter()

void SurgSim::Devices::FilteredDevice::addFilter ( std::shared_ptr< DeviceFilter > filter )

Adds a DeviceFilter.

The first filter that is added will be connected to the raw/base device. The last filter that is added will interface with InputConsumers and/or an OutputProducer. Any filters added in-between will be connected in order.

Parameters

filter A DeviceFilter.

§ getDevices()

const std::vector< std::shared_ptr< Input::DeviceInterface > > & SurgSim::Devices::FilteredDevice::getDevices ( ) const

Returns: All devices.

§ hasOutputProducer()

bool SurgSim::Devices::FilteredDevice::hasOutputProducer ( )

overridevirtual

Query if this object has output producer.

Returns: true if there is an output producer, false if not.

Implements SurgSim::Input::DeviceInterface.

§ initialize()

bool SurgSim::Devices::FilteredDevice::initialize ( )

overridevirtual

Fully initialize the device.

When the manager object creates the device, the internal state of the device usually isn't fully initialized yet. This method performs any needed initialization.

Implements SurgSim::Input::DeviceInterface.

§ isInitialized()

bool SurgSim::Devices::FilteredDevice::isInitialized ( ) const

overridevirtual

Returns: true if the device has been initialized and has not yet been finalized.

Implements SurgSim::Input::DeviceInterface.

§ setDevice()

void SurgSim::Devices::FilteredDevice::setDevice ( std::shared_ptr< Input::DeviceInterface > device )

Sets the raw/base device.

Parameters

device The device connected to the filter(s).

§ setDevices()

bool SurgSim::Devices::FilteredDevice::setDevices ( const std::vector< std::shared_ptr< Input::DeviceInterface >> & devices )

Sets the devices.

Parameters

devices All the devices.

Returns: true on success

The documentation for this class was generated from the following files:

SurgSim/Devices/DeviceFilters/FilteredDevice.h
SurgSim/Devices/DeviceFilters/FilteredDevice.cpp
